Stativhøyttalere

Audio Solutions

PERFECTION

Development of these fine speakers is a true challenge. We combine laws of physics with design, manufacturing stability and customers' needs to make perfect speakers. Every smallest part is hand crafted and inspected for any flaws.

Audio Solutions Vantage B                                                                                       Pris 594,000.-

Dimensions (HxWxD) : 1281 mm x 392 mm x 553 mm; 50.4 x 15.4 x 21.8in

Weight : 50 kg/110 lbs each

Sensitivity : 90 dB @ 2.83V 1m

Recommended power amplifier : 30-400 W rms

Impedance : nominal 4,0 ohms;

Crossover frequency : 150, 8000 Hz

Frequency response (in-room environment) : 30-30000 Hz

Drivers : 2,5 cm beryllium dome tweeter, 17 cm Egyptian Papyrus mid, 22 cm paper woofer

Audio Solutions Virtuoso B                                                                                Pris fra 171,600 - 205,900.-

Virtuoso B Stand                                                                                                      Pris  43,800.-

Dimensions (HxWxD) : 450mm x 297mm x 478mm

Dimensions with stand (HxWxD) : 1225mm x 391mm x 547mm

Weight without stand : 23 kg

Weight with stand : 37 kg

Shipping weight : 60 kg/

Sensitivity : 91.5 dB @ 2.83V 1m

Nominal power handling : 130 W rms

Maximum unclipped power handling : 260 W;

Impedance : nominal 4,0 ohms

Crossover frequency : 500 Hz; 7000 Hz

Frequency response (in-room environment) : 30-30000 Hz

Drivers : 3cm silk dome tweeter, 16.5cm Hard Pulp paper cone mid, one 19cm Hard Pulp cone bass driver firing down

Audio Solutions Figaro BL2                                                                                                        Pris 57,500.-

SPECIFICATION

Dimensions (HxWxD) : 400mm x 265mm x 402mm; 15.75 x 10.43 x 15.83in

Weight : 15 kg/33 lbs each

Shipping weight : 18 kg/39.7 lbs each

Sensitivity : 90.5 dB @ 2.83V 1m

Suggested amp power : 10-200 W;

Impedance : nominal 4,0 ohms;

Crossover frequency : 4000 Hz

Frequency response (in-room environment) : 39-25000 Hz

Drivers : 19mm silk dome tweeter, 18.3cm ER paper cone mid-bass driver

Audio Solutions Figaro B  2                                                                                                       Pris 42,900

 SPECIFICATION

Dimensions (HxWxD) : 337mm x 223mm x 339mm; 13.27 x 8.78 x 13.35in

Weight : 10 kg/22 lbs each

Shipping weight : 12 kg/26.4 lbs each

Sensitivity : 89.5 dB @ 2.83V 1m

Suggested amp power : 5-150 W;

Impedance : nominal 4,0 ohms;

Crossover frequency : 4000 Hz

Frequency response (in-room environment) : 42-25000 Hz

Drivers : 19mm silk dome tweeter, 15.2cm ER paper cone mid-bass driver

Audio Solutions Overture O302B                                                                           Pris fra 20,400 - 24,500.-

Dimensions (HxWxD) : 360mm x 210mm x 330mm; 14.4 x 8.3 x 13 in

Weight : 9 kg/19 lbs each

Shipping weight : 12 kg/26 lbs each

Sensitivity : 90 dB @ 2.83V 1m

Nominal power handling : 70 W rms

Maximum unclipped power handling : 140 W;

Impedance : nominal 4,0 ohms

Crossover frequency : 3000 Hz

Frequency response (in-room environment) : 47-26000 Hz

Drivers : 2,5 cm silk dome tweeter, 15.2 cm ER paper cone mid-bass driver

Fischer & Fischer

Kommer snart på lager

Frequency response (+/- 3 dB)45 - 25.000 Hz

Impedance4 ohms

Sensitivity86 dB (1 W / 1 m)Max. acoustic pressure105 dB

Frequency dividing network2nd order impedance corrected filterFunction principlebass reflexBass and midrange systemone long excursion cone speaker 145 mm alloy cone, special coatedMidrange and treble-systemone dome tweeter 28 mmCabinetmanufactured of 15 / 20 mm thick natural slateDimensions (H x W x D)330 x 190 x 250 mmWeight17,5 kg.

                                                                                                                             Pris SN 46,800.-

                                                                                                                                    SL 62,400.-

Frequency response (+/- 3 dB) 60 - 30.000 Hz
Impedance 4 ohms
Sensitivity 85 dB (1 W / 1 m)
Max. acoustic pressure 105 dB
Function principle bass reflex
Bass-midrange system 100 mm long piston bass-midrange speaker with paper membrane
Treble system 22 mm silk dome tweeter and neodymium magnet system
Connecting terminal Single Wire
Cabinet material 12 / 20 mm thick low-resonance natural slate
Dimensions slate cabinet (H x W x D) 200 mm x 130 mm x 200 mm
Weight 7,1 kg.                                                                                                        Pris 43,200.-

Ophidian

Mojo 2

Funksjoner

• Dobbel 115 mm belagt papirmidbass med kraftige motorsystemer

• 27mm neodym høyfrekvent enhet med en Sonolex belagt stoff membran

• AEROFLEX-portsystem for nøyaktig kontrollert bassytelse

• Avstivet og optimalisert skap bygget i Storbritannia

• Avtakbare magnetiske beskyttelsesgitter

Spesifikasjoner

• Frekvensrespons - 52Hz til 25khz (-3dB)

• Følsomhet - 86dB (2.83v)

• Anbefalt effekt - 40 til 120 watt

• Impedans - 4 ohm

• Dimensjoner - 286mm H x 158mm B x 220mm D (inkl. gitter)

• Vekt - 4,4 kg.                                                                                                                 Pris 19,690.-

Minimo 2

Funksjoner

• 115 mm belagt papir midbass med kraftig motorsystem

• 27mm neodym høyfrekvent enhet med en Sonolex belagt stoff membran

• AEROFLEX-portsystem for nøyaktig kontrollert bassytelse

• Avstivet og optimalisert skap bygget i Storbritannia

• Avtakbare magnetiske beskyttelsesgitter

Spesifikasjoner

• Frekvensrespons - 53Hz til 25khz (-3dB)

• Følsomhet - 85dB (2.83v)

• Anbefalt effekt - 40 til 80 watt

• Impedans - 4 ohm

• Dimensjoner - 210mm H x 132mm B x 190mm D (inkl. gitter)

• Vekt - 2,6 kg.                                                                                                                Pris 15,475.-

PMC

Available Finishes:Walnut, Diamond Black, Oak, White Silk
Crossover Frequency:1.7kHz
Dimensions:H 410mm (16.1") x W 192mm (7.6") x D 373mm (14.7") incl. binding posts (+9mm grille)
Drive Units:LF PMC 6.5"/170mm long-throw g-weave™ cone with cast alloy chassis HF PMC/SEAS®, 19mm twenty5i series, SONOMEX™ fabric soft dome, Ferrofluid cooled, with 34mm surround and dispersion grille
Effective ATL™ Length:2m (6.5ft)
Frequency Response:39Hz - 25kHz
Impedance:8 Ohm
Input Connectors:One pair 4mm binding posts
Recommended Amp Power:15 - 200W
Recommended Drive Unit Torque Settings:HF: 0.6Nm LF: 0.75Nm
Weight:10kg (22 lbs ea.)                                                                                           Pris: 47,700.-

Available Finishes: Walnut, Diamond Black, Oak, White Silk

Crossover Frequency: 1.7kHz

Dimensions: H 340mm 13.4" x W 162mm 6.4" x D 284mm 11.2" incl. binding posts (+9mm grille)

Drive Units: LF PMC 5.5"/140mm long-throw g-weave™ cone with cast alloy chassis

HF PMC/SEAS®, 19mm twenty5i series, SONOMEX™ fabric soft dome, Ferrofluid cooled, with 34mm surround and dispersion grille

Effective ATL™ Length: 1.72m 5.6ft

Frequency Response: 46Hz - 25kHz

Impedance: 8 Ohm

Input Connectors: One pair 4mm binding posts

Recommended Amp Power: 25 - 150W

Recommended Drive Unit Torque Settings: HF: 0.6Nm LF: 0.75Nm

Weight: 6kg (13.2 lbs ea.)                                                                                         Pris: 31,900.-

Available Finishes: Jet Black
Crossover Frequency:2kHz
Dimensions:H 290mm 11.4" x W 155mm 6.1" x D 234mm 9.19" (+ grille)
Drive Units:LF - PMC Doped 140mm cast alloy chassis
HF - 27mm fabric soft dome
Effective ATL™ Length:1.5m 4.92ft
Frequency Response:50Hz-25kHz
Impedance:8 Ohms
Input Connectors:2 pairs 4mm sockets
sensitivity:87dB 1w 1m
Weight:4.5kg (9.9lbs)                                                                                                Pris: 22,450.-

Available Finishes:Silk Black

Crossover Frequency:1.7kHz

Horizontal Directivity:80 degrees

Vertical Directivity:70 degrees

Dimensions:H 320mm 35.7" W 162mm 6.4" D 237mm 9.3" (+10mm optional grille)

Drive Units:LF PMC 5.25"/133mm natural fibre long-throw LT™
F PMC 27mm /1" soft domeEffective

ATL™ Length:1.91m 6.3ft

Frequency Response:35Hz – 25kHz (-3dB)

Impedance:6 Ohm

Input Connectors:One pair 4mm binding posts

Sensitivity:87.5dB SPL 1W 1m

Peak SPL:124dB SPL

Recommended Amp Power:20 – 250W

Weight:4.5kg 9.9lbs ea.

Options:prodigy1 grille                                                                                                                 Pris 15,490.-
